Drizzle

Optional Drizzle ORM interoperability over dbSDK-owned connections - typed schema queries on the same pool, with dbSDK keeping the lifetime, TLS posture, and guarded-pooler rules.

dbsdk/drizzle is an optional interoperability entry: it hands Drizzle ORM’s stable node-postgres / neon-http drivers a validated, dbSDK-owned driver handle, so you can use Drizzle’s typed schema, query builder, and relational queries on the same pool dbSDK manages — without giving up the lifetime ownership, TLS posture, and guarded-pooler rules that dbSDK enforces.

Its companion entry dbsdk/orm is the SDK-owned schema authoring surface for the same stable drizzle-orm copy: one import for tables, columns, relations, operators, and sql (see Schema authoring with dbsdk/orm).

dbSDK does not fork or wrap Drizzle. Schemas and builders are imported from dbsdk/orm (a pure re-export) or from drizzle-orm directly — both resolve to the same stable 0.45.3 API; the bridge only supplies the connection and refuses anything that would bypass it. There is no claim of full Drizzle parity here — Studio, Kit, seed, and validators are separate tools with their own licenses.

Install

drizzle-orm is an optional peer dependency (^0.45.3, the stable line — not the 1.0 RC). The SDK itself stays dependency-free; the Drizzle entry is lazy, so installing nothing extra keeps dbsdk imports untouched.

npm i drizzle-orm@^0.45.3   # or: pnpm add drizzle-orm@^0.45.3

Calling a factory without the peer installed fails before any dispatch with an actionable install hint.

A note for skipLibCheck: false users: drizzle-orm 0.45.3’s own published type declarations do not fully typecheck under strict NodeNext even in a bare drizzle consumer (~72 upstream errors, with or without dbsdk). With all optional peers you use installed, dbsdk’s packed declarations contribute zero errors. If you omit @neondatabase/serverless (legitimate when you only use dbsdk/postgres + dbsdk/drizzle), skipLibCheck: false reports 2 unresolved-optional-peer-type errors in dbsdk’s own .d.ts — the same pattern as upstream drizzle entries for their optional peers. skipLibCheck: true (the setting used for every other dbSDK entry) avoids all of this.

The shape

import { createDatabase } from "dbsdk";
import { postgres } from "dbsdk/postgres";
import { drizzlePostgres } from "dbsdk/drizzle";
import { pgTable, serial, text } from "drizzle-orm/pg-core";

const users = pgTable("users", {
  id: serial("id").primaryKey(),
  email: text("email").notNull(),
});

const db = createDatabase({
  adapter: postgres({ connectionString: process.env.DATABASE_URL! }),
});

const drizzleDb = await drizzlePostgres(db, { schema: { users } });
const rows = await drizzleDb.select().from(users); // fully typed

await db.close(); // YOU still own the lifetime — Drizzle never ends the pool

Both factories are async (they lazy-import the driver) and take the same config subset: { schema, logger, casing } — a subset of Drizzle’s stable DrizzleConfig<TSchema>, so schema/relations/logger/casing generic inference is preserved exactly.

• drizzlePostgres(db, config?) → Drizzle’s NodePgDatabase<TSchema> with $client set to the dbSDK-owned pool.
• drizzleNeonHttp(db, config?) → Drizzle’s NeonHttpDatabase<TSchema> with $client set to the dbSDK-owned neon query function.

Schema authoring with dbsdk/orm

dbsdk/orm is a pure re-export of the stable drizzle-orm 0.45.3 root and pg-core namespaces as a single import — no renames, no wrappers, no upstream code copied, zero runtime logic (no connection, no pool, no dispatch). It is PostgreSQL-focused authoring only: no other dialect surfaces, and no Studio, Kit, seed, or migration tooling is shipped here.

import { createDatabase } from "dbsdk";
import { postgres } from "dbsdk/postgres";
import { drizzlePostgres } from "dbsdk/drizzle";
// Authoring comes from ONE import; execution still goes through dbsdk/drizzle.
import { pgSchema, pgTable, serial, text, integer, relations, eq, asc } from "dbsdk/orm";

const app = pgSchema("myapp");
export const users = app.table("users", {
  id: serial("id").primaryKey(),
  email: text("email").notNull(),
});
export const posts = app.table("posts", {
  id: serial("id").primaryKey(),
  authorId: integer("author_id").notNull(),
  title: text("title"),
});
export const usersRelations = relations(users, ({ many }) => ({ posts: many(posts) }));
export const postsRelations = relations(posts, ({ one }) => ({
  author: one(users, { fields: [posts.authorId], references: [users.id] }),
}));

const db = createDatabase({
  adapter: postgres({ connectionString: process.env.DATABASE_URL! }),
});

const drizzleDb = await drizzlePostgres(db, {
  schema: { users, posts, usersRelations, postsRelations },
});

// Typed join select + relational query on the dbSDK-owned pool.
const joined = await drizzleDb
  .select({ email: users.email, title: posts.title })
  .from(users)
  .innerJoin(posts, eq(posts.authorId, users.id));
const feed = await drizzleDb.query.users.findMany({ with: { posts: true } });

await db.close(); // YOU still own the lifetime — Drizzle never ends the pool

Behavior details:

• Same optional peer as the bridge. dbsdk/orm re-exports the exact objects dbsdk/drizzle resolves, so a normal install has one physical drizzle-orm copy and schemas authored through the facade just work through the bridge. This shared-peer resolution is the mechanism that keeps a second incompatible copy out of a normal install — it is not an absolute guarantee against unusual dependency layouts that force one.
• Without the peer, only this subpath fails. The dbsdk root entry never imports dbsdk/orm. If drizzle-orm is not installed, importing dbsdk/orm fails with Node’s standard module-resolution error naming the missing dependency (root imports are unaffected); dbsdk/drizzle keeps its actionable factory-time refusal.
• Full upstream surface, familiar API. The export * re-exports keep 100% upstream API fidelity (the five type names exported by both root and pg-core resolve explicitly to the pg-core specializations). Two stable quirks to know: one/many are callback-injected inside relations(table, ({ one, many }) => …), not module-level exports, and pg-core’s client-free QueryBuilder is SELECT-only — INSERT/UPDATE/DELETE builders come from an instance created via dbsdk/drizzle.
• Strict TypeScript. The packed declarations compile under NodeNext + exactOptionalPropertyTypes + noUncheckedIndexedAccess with zero dbSDK-attributed errors (skipLibCheck: true; with skipLibCheck: false the ~72 reported errors are all inside drizzle-orm’s own published d.ts — the same upstream boundary as the bridge, unchanged by the facade).

Supported modes

The bridge is deliberately narrow. It accepts what it can verify:

Refused before the raw handle is touched or any pool is created, with a DbError code CONFIGURATION:

• Transaction-mode poolers (sessionState: false), e.g. Supabase connectionMode: "transaction". dbSDK’s per-statement session-state guards live in its query functions, not in the pool — Drizzle executes through the pool directly and would bypass them. Use direct or session mode instead.
• HTTP databases passed to drizzlePostgres (use drizzleNeonHttp) and TCP databases passed to drizzleNeonHttp (use drizzlePostgres).
• Neon’s websocket transport. Its raw.pool is structurally pg-compatible, but dbSDK has not verified that mode for this bridge, so it is refused rather than claimed.

No DSN, no connection, no client

Drizzle’s own drizzle() also accepts a connection string or a { connection: ... } config and would construct its own pg.Pool or neon() client. That would silently bypass dbSDK’s pool configuration — including TLS with certificate verification on by default, CA pinning, and lifetime ownership. The bridge therefore accepts only a validated dbSDK-owned handle:

await drizzlePostgres(db, { connection: "postgres://..." }); // TypeScript error
await drizzlePostgres(db, { client: somePool });             // TypeScript error
await drizzlePostgres("postgres://..." as never);            // TypeScript error

JavaScript callers hit the same refusals at runtime, before any dispatch. No error message ever contains your connection string.

What the bridge does not change (honest boundaries)

• Errors. Only the bridge’s pre-execution validation uses dbSDK error conventions (DbError, code CONFIGURATION). Queries, transactions, and batches executed through the returned Drizzle instance surface native Drizzle/driver errors — they are not normalized into DbError, and dbSDK’s indeterminate-write semantics do not extend to Drizzle’s executor.
• Lifetime. db.close() ends the pool. A previously returned Drizzle instance then fails on use (the pool was ended) and is never recreated. For Neon HTTP there is no pool to end, so a previously returned instance keeps working after close — there is simply nothing to release.
• Prepared statements. Over TCP, Drizzle may use its own prepared statements; dbSDK’s “no named prepared statements” invariant applies to dbSDK’s own executor, not to Drizzle’s. Over Neon HTTP there are no prepared statements at all.
• Neon HTTP limits are the driver’s, unchanged: no interactive transactions (db.transaction on the Drizzle instance throws), no session state, no automatic WebSocket fallback, no retry. Use dbSDK’s db.batch for atomic multi-statement writes, or a transaction transport on the adapter for dbSDK-level transactions.

What is next

The next workflow unit is the migration lifecycle: provision via management, get the connection string, generate and apply schema with drizzle-kit (generate/push, dev-time CLI) and drizzle-orm/migrator’s migrate() over this same bridge, then seed. This page will show that end-to-end when it lands.
